SLS 380

Specifications of the SLS 380:

1. Technology:

• 3D Printing Technology: Selective Laser Sintering (SLS)
• Laser Type: High-powered CO2 laser for efficient and precise sintering of polymer powders.

2. Build Volume:

• Max Build Size: Approximately 380 x 380 x 460 mm (15 x 15 x 18 inches)
• The large build volume is suitable for producing sizable parts or high-volume batches of smaller components.

3. Print Resolution and Accuracy:

• Layer Thickness: Adjustable layer thickness ranging from 60 to 120 microns, allowing for flexibility between high detail and faster print speeds.
• Accuracy: High precision with tolerances typically within ±0.1 mm or better, depending on the size and complexity of the part.
• Detailing: Capable of reproducing fine features and intricate geometries with consistent quality.

4. Materials:

• Material Type: Supports a range of advanced nylon powders and composite materials.
• Material Options: Includes options such as PA 12, PA 11, glass-filled nylon, and other engineering-grade materials.
• Properties: Materials provide high tensile strength, flexibility, impact resistance, and heat resistance to suit different engineering and functional requirements.

5. Surface Finish:

• Surface Quality: Produces a slightly rough, matte finish typical of SLS parts, which can be post-processed for a smoother appearance if needed.
• Post-Processing: Options include dyeing, polishing, and coating to enhance aesthetics and performance.

6. Software Integration:

• Software: Equipped with powerful build preparation software that offers part nesting, orientation optimization, and print parameter customization.
• File Support: Compatible with STL, OBJ, 3MF, and other common 3D file formats.
• Connectivity: Supports cloud-based or on-premises monitoring and management.

7. User Interface and Control:

• Interface: Intuitive touch-screen panel or computer interface for easy setup, monitoring, and operation.
• Automation Features: Includes automated material handling, powder distribution, and part cooling to streamline the printing process.
• User Control: Customizable print settings allow users to optimize for specific materials and part requirements.

8. Applications:

• Functional Prototyping: Produces strong, durable prototypes that can be used for functional testing and validation.
• Production Parts: Suitable for low to medium-volume production of final parts with complex designs that are difficult to achieve with traditional manufacturing.
• Tooling and Fixtures: Effective for producing custom jigs, fixtures, and tooling components with high strength and precision.
• Complex Assemblies: Ideal for creating interlocking and movable parts directly in the build chamber without the need for support structures.

Key Advantages:

• High Productivity: The large build volume and fast printing speeds enable efficient batch production and lower per-part costs.
• Material Versatility: Supports a wide range of engineering-grade materials, providing flexibility for various applications.
• Consistent Quality: Advanced thermal control and laser precision ensure uniform part quality across the entire build volume.
• Automated Workflow: Features automated material handling and part removal to reduce operator workload and improve safety.
• Scalable Solution: Suitable for prototyping and scaling up to low-volume manufacturing with reliable and repeatable results.

The SLS 380 is a powerful and versatile 3D printing solution for companies looking for precision, reliability, and productivity in their additive manufacturing processes. It is particularly valuable for applications that require durable, functional parts with complex geometries.
